16GB Exascend Essential-X DDR4 SO-DIMM 3200MT/s ES16G4S3200AU

The Exascend Essential-X 4GB DDR4 SO-DIMM is an unbuffered memory module (Small Outline Dual In-Line Memory Module) designed for use as system memory in devices such as laptops, mobile PCs, and micro-servers. This 4GB variant is suitable for basic tasks or for supplementing existing memory.

The module operates at 3200MT/s (1600MHz clock speed) using the standard JEDEC voltage of 1.2V. It is built using DDR4 SDRAM chips in FBGA packaging mounted on a 260-pin PCB and features a 4Kbit serial EEPROM for SPD. Additionally, the module supports on-die termination (ODT), a bi-directional differential data strobe, 8-bit prefetch, and asynchronous reset. The module is RoHS compliant.

Specifications

• Capacity: 16GB
• Type: DDR4 SDRAM, unbuffered
• Form factor: SO-DIMM, 260-pin
• Speed: 3200MT/s (1600MHz clock)
• Voltage: 1.2V ± 0.06V (VDDQ 1.2V)
• Chip package: FBGA
• SPD: 4Kbit serial EEPROM
• Features: On-die termination (ODT), bi-directional differential data strobe, 8-bit prefetch, asynchronous reset
• Operating temperature: 0 to 85°C (DRAM case temperature)
• Environmental: RoHS compliant
