Always stay online and prevent data loss
As soon as the power fails, an APC Smart-UPS immediately provides emergency power to all connected equipment. Because an APC UPS automatically does this you prevent unwanted outages of, for example, a PC, server or switch. With the supplied Powershute software you can even have critical IT hardware automated and controlled shutdown. This prevents data loss, downtime and physical damage to hardware.
Safety
In addition, a Smart-UPS protects connected devices against peak voltage, among other things, caused by lightning. This APC emergency power supply is ideally suited for (small) business use.
Easy in use
Thanks to the preinstalled APC Network Management Card (AP9630) you can connect these ups directly to your network. For example, the APC UPS is easy to manage remotely and can send a shutdown signal to multiple physical and / or virtual servers via the network.
Extend the lifespan
The SUA5000RMI5U contains two internal battery cartridges (RBC55) and these can be replaced simply, safely and independently by the user. This without having to disable the APC UPS or connected equipment. This way you can easily and cheaply extend the life of the APC Smart-UPS and your equipment will always stay online.
Warranty extension
The factory warranty of the SUA5000RMI5U is 2 years and can be upgraded to 5 years with the APC service pack (WBEXTWAR3YR-SP-05).
Power
Output power capacity: 5000 VA
Output power: 4000 W
Input operation voltage (min): 151 V
Input operation voltage (max): 302 V
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Power supply input frequency: 50/60
Surge energy rating: 480 J
Efficiency: 96%
Output frequency regulation: 47 - 53
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
AC outlets quantity: 10 AC outlet(s)
Number of output IEC jumpers: 4
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery recharge time: 3 h
Typical backup time at half load: 26.7 min
Typical backup time at full load: 9.4 min
Replacement battery cartridge: RBC55
Hot-swap battery: Yes
Cold start: Yes
Automatic battery test: Yes
Battery replacement alarms: LED
Battery life (max): 5 year(s)
Battery capacity: 1632 VAh
Design
Form factor: Rackmount/Tower
Colour of product: Black
Rack capacity: 5U
Performance
UPS topology: Line-Interactive
Number of output phases: 1
Hold time (min): 2 ms
Hold time (max): 4 ms
Performance
Surge protection: Yes
Waveform: Sine
Automatic Voltage Regulation (AVR): Yes
Auto-restart: Yes
Noise level: 53 dB
LED indicators: Yes
Audible alarm(s): Yes
Technical details
Input connections: Hard Wire 3-wire
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 9000 m
Non-operating altitude: 0 - 15000 m
Certificates
Certification: C-tick, CE, EN 50091-1, EN 50091-2, GOST, GS Mark, VDE, REACH, PEP, EOLI
RoHS compliance: Yes
Weight & dimensions
Width: 483 mm
Depth: 660 mm
Height: 222 mm
Weight: 97.7 kg
